004-25NFRX8-279

下载: 规格 平面图 3D模型
  • 全范围频率响应

  • 非常小的外形尺寸

  • 优化的频率响应

      请选择规格

    • 阻抗:
      2-3Ω
    • 材料:
      钕磁铁
      铁氧体磁铁
      铁钕复合磁
    • 音圈:
      1~2英寸
      2~3英寸
      3~4英寸
获取免费报价

我们只做最好

基本参数
标称直径:2.5英寸
额定阻抗:8欧姆
功率处理
AES功率:20瓦
峰值功率:40瓦
音圈
直径:0.8英寸
绕线:铜包铝线(CCAW)
音圈骨架:Kapton材质
音圈绕组高度:8.3毫米
T/S参数
谐振频率:123赫兹(Hz)
直流电阻:7.3欧姆
电学品质因数:0.81
机械品质因数:5.97
总品质因数:0.71
等效容积:0.46升
等效容积:21.2cm²
振动系统质量:2.2克
力因子:4
音圈电感:0.09毫亨
灵敏度:82.69分贝
设计细节
悬边材料:橡胶
振膜材料:
弹波材料:Nomex
磁路板厚度:3毫米
振膜线性位移峰峰值:7.8毫米
整体直径:65毫米
螺栓孔中心直径:73毫米
面板开孔直径:56毫米
深度 (从法兰至后部的距离):37毫米
净重:0.18kg
订购代码
8欧姆版本:142FCDX8 ohm-557A
修复套件:

25NFR was designed around neodymium ring magnet. The magnetic structure delivers very high level of magnetic force, while generating minimum amount of modulation distortion. The lightweight, yet strong, paper cone with attached rubber surround was designed and optimized to deliver the highest level of performance in full-range applications. This speaker finds its best application in columns or multi-way Hi-Fi products. Due to its excellent HF response, further usage of HF units is not required. The small form-factor allows this product to be used in space limited applications or portable products.


25NFR 扬声器采用钕磁铁磁路系统设计。该磁路结构能提供极强的磁力,同时将调制失真降至最低。

其轻量化且高刚性的纸质振膜搭配橡胶折环,经过专门优化,可在全频段应用中提供卓越的性能表现。

这款扬声器尤其适合用于 音柱 或 多分频Hi-Fi产品。由于其出色的高频(HF)响应,无需额外增加高音单元。

紧凑的外形设计使其适用于空间受限的应用场景或便携式产品。
